HEIDENHAIN

Sealed linear encoders

Sealed linear encoders feature optimal protection from dust, chips, and splash water. They are especially ideal for use in manually operated machine tools and also in numerically controlled machine tools.

LC 100 series

  • Absolute linear encoders

  • Full-size scale housing

  • High vibration tolerance

  • Also available with functional safety

  • LC 400 series

  • Absolute linear encoders

  • Slimline scale housing

  • Also available with functional safety

  • LC 200 series

  • Absolute linear encoders

  • Full-size scale housing

  • High vibration tolerance

  • Long measuring lengths of up to 28 m

LB 382

  • Incremental linear encoder

  • Full-size scale housing

  • Long measuring lengths of up to 72 m

LF 185

  • Incremental linear encoder

  • Full-size scale housing

  • Very high repeatability

LF 485

  • Incremental linear encoder

  • Slimline scale housing

  • Very high repeatability

LS 100 series

  • Incremental linear encoders

  • Full-size scale housing

  • High vibration tolerance

LS 400 series

  • Incremental linear encoders

  • Slimline scale housing

  • For limited installation space

LS 600 series

  • Incremental linear encoders

  • Full-size scale housing

  • For manually operated machines

HEIDENHAIN

HEIDENHAIN EXPOSED ENCODERS:

Exposed linear encoders

Exposed linear encoders have zero mechanical contact between the scanning head and the scale or scale tape. Applications include production and measuring equipment in the semiconductor industry, as well as pick-and-place machines and direct drive systems.

LIC 4100 series

  • Absolute linear encoders

  • High accuracy and large measuring lengths

  • Different mounting options

  • Graduation on steel scale tape, glass-ceramic, or glass

  • Available with functional safety

LIC 3100 series

  • Absolute linear encoders

  • High accuracy and long measuring lengths

  • Various mounting options

LIC 2100 series

  • Absolute linear encoders

  • Wide mounting tolerances

  • For simple applications

LIP 300 series

  • Incremental linear encoders

  • Very high accuracy

  • Very short signal periods



LIP 200 series

  • Incremental linear encoder

  • Very high accuracy

  • Very short signal periods

  • High traversing speeds

  • Large measuring lengths

LIP 6000 series

  • Incremental linear encoders

  • Very high accuracy

  • High traversing speeds

  • Large measuring lengths

  • For tight installation spaces

  • Limit switch and homing track

LIF 400 series

  • Incremental linear encoders

  • Very high accuracy

  • Convenient adhesive fastening for scale

  • Limit switch and homing track

LIDA 400 series

  • Incremental linear encoders

  • High accuracy and large measuring lengths

  • Different mounting options

LIDA 200 series

  • Incremental linear encoders

  • Wide mounting tolerances

  • For simple applications

  • Easy installation with integrated signal-quality indicator

PP 281 two-coordinate encoder

  • PP 281 incremental two-coordinate encoder

  • Wide-surface phase grating structure on graduation carrier

  • High-accuracy position measurement within plane

HEIDENHAIN

  • Digital Readout Systems and Interface Electronics

  • It’s understood that applications from machine tools to measuring microscopes contain some error in the accuracy of moving components when compared to a known standard.

Digital readout systems (or position display units) and interface electronics from HEIDENHAIN and ACU-RITE can address these issues—offering increased accuracy and quality control in myriad applications:

  • ACU-RITE readout systems use a function called Position-Trac™ that enables quick, easy workpiece zero-reset after power loss.

  • Both linear and non-linear error compensation, up to ±99999 ppm (parts per million), can be entered into the readout.

  • With the greater positioning accuracy of the system, the inherent accuracy of the machine is used in full, and the likelihood of errors is greatly reduced.

  • ACU-RITE readout systems use a function called Position-Trac™ that enables quick, easy workpiece zero-reset after power loss.

  • Both linear and non-linear error compensation, up to ±99999 ppm (parts per million), can be entered into the readout.

  • With the greater positioning accuracy of the system, the inherent accuracy of the machine is used in full, and the likelihood of errors is greatly reduced.

For machine tool operators, the benefits of DROs are substantial:

  • The time the operator used to spend setting the coordinates for positioning is now spent machining more parts. This translates into greater operator efficiency and in turn, increased output.

  • The elimination of paper-and-pencil calculations for offsets or other dimensions that may not appear on the drawings.

  • A reduction in operator fatigue associated with counting hand wheel turns and straining to read verniers.

  • Digital measuring system makes training of new or less-experienced operators much easier and less time consuming.

HEIDENHAIN offers the right digital readout for every type of machine, including milling machines, lathes, grinding machines, drilling machines, and radial drilling machines. A splash-water-resistant front panel and a rugged cast-metal housing equip them to handle harsh ever day shop floor conditions.

VIEW: ACU-RITE PRODUCTS
