FRYER VERTICAL MACHINES
Fryer's CNC Vertical Machining Centers come in these series:
MC-B Series, MC-L Series, VB Series, TC-V Series.
FRYER MC-B SERIES
Box Way Performance Machining Centers
Fryer’s MC-B Series offers the ultimate in performance by featuring heavyweight castings with box way construction.
The standard 24 tool arm type ATC and 1,200 IPM rapids produce more parts per hour.
Fully digital control and drives combined with fast set-up and programming maximize performance and reliability.
-
Heavy duty box ways
-
Fast 1,200 IPM rapids
-
24 tool arm type ATC
-
High torque 30 HP motor (40 HP option)
-
40 or 50 taper spindles
-
Compact size
-
Fast conversational programming
-
Fast set-up keys
-
Absolute encoders
-
Regenerative drive technology
-
Chip management system
-
Coolant thru spindle
MC-30B
30" x 18" x 22"
MC-40B
40" x 20" x 28"
MC-45B
45" x 25" x 25"
MC-60B
60" x 30" (35”) x 28" (38")
MC-80B
80" x 35" (40") x 30" (34")
MC-100B
100" x 35" (40") x 30" (34")
Find Out More:
FRYER: MC-L SERIES
Linear Way High Speed Machining Centers
The Fryer MC-L series features high speed and high performance. Standard features include high speed 30 tool ATC, a 10,000 RPM inline spindle, a high torque 30 HP motor and a super-fast 1,450 IPM rapid feedrate. Combined with roller type linear ways and heavy-duty FEA designed castings, the MC-L series is the ultimate compact VMC.
-
Roller type linear ways
-
Fast 1,450 IPM rapids
-
30 tool arm type ATC
-
High torque inline 30 HP motor
-
40 taper Big Plus – 10,000 RPM
-
Compact size
-
Fast conversational programming
-
Fast set-up keys
-
Absolute encoders
-
Regenerative drive technology
-
Chip management system
-
Coolant thru spindle.
MC-24L
24” x 16” x 17”
MC-30L
30” x 20” x 20”
MC-40L
40” x 22” x 22”
MC-45L
45” x 25” x 25”
MC-60L
60” x 30” (35”)
x 28” (38”)
Find Out More:
FRYER VB SERIES:
Extra Large Machining Centers:
Designed as a high-performance machining center without an enclosure, the Fryer VB Series offers versatility and value.
Ideal for production and job shop applications, the VB open design and rugged construction allows for easy loading of large parts.
Extremely simple set-up and programming make this machine highly efficient for even short run parts.
The VB series is also equipped with an impressive set of standard features unmatched by any machine in its class.
-
Box way construction with Turcite B liners
-
Extra-large travel up to 160" x 50"
-
Rugged 40 and 50 taper spindle
-
Automatic tool changer
-
Rigid tapping with peck feature
-
High volume flood coolant system
-
Fast conversational programming
-
Fast set-up keys
-
Absolute encoders
-
Regenerative drive technology
-
Available full guarding
-
Coolant thru spindle
VB-60
60" x 30" x 28"
VB-80
80" x 35" (40") x 26" (34")
VB-100
100" x 35" (40") x 26" (34")
VB-120
120" x 40" (50") x 40"
VB-160
160" x 40" (50") x 40"
FRYER TC-V
Vertical Traveling Column
The Fryer TC-V Series features a fixed table and traveling column for flexibility with large parts and fixturing.
You can use the machine as a multi-pallet design by using the table dividers to create work zones.
The fixed table allows table loads of more than 10,000 lbs. and is available with a built-in rotary table.
The high torque 40 and 50 taper spindles feature available CTS and gearbox.
Available Y axis travel of 24" or 32" and in sizes ranging from 40" X travel all the way to a huge 320" travel machine.
-
Traveling column design
-
Fixed table with 10,000 lbs. plus capacity
-
24 tool arm type ATC
-
1,000 IPM rapid
-
Y travel of 24" or 32"
-
Siemens or Fanuc CNC
-
Standard or tilting head spindle
-
Built-in 24" or 32" flush rotary table
-
Table mounted 4th axis and tailstock
-
Fast conversational programming
-
Fast set-up keys
-
Open style semi-guarding or fully enclosed.
TC-40V
40" x 26" x 28"
TC-80V
80" x 24" (32") x 24" (32")
TC-120V
120" x 24" (32") x 24" (32")
TC-160V
160" x 24" (32") x 24" (32")
TC-240V
240" x 24" (32") x 24" (32")
TC-320V
320" x 24" (32") x 24" (32")
